Advantages:
● Hybrid Integration: Our connector seamlessly combines Power and Signal in a single interface, drastically reducing installation time and cabling costs.
● High Voltage Performance: Engineered for power-hungry projects with a robust 380V (Power)+ 60V (Signal) capability, ensuring stable
energy distribution and precise control over long distances.
● Certified Reliability: In an industry where safety is non-negotiable our connectors are UL2238 certified.
| Mating Cycle: 500 Cycles | Voltage Rating: 380V (Power)+ 60V (Signal) | Operating Temperature: -40°C to 105°C |
| Wire Processing: Solder | Current Rating: 15A + 2A | IP Rating: IP67(Mated) |
| Insulation Resistance: 100MΩ at 500V DC | Withstand Voltage: 2,000V AC | Salt Spray: 5% NaCI, 48h |
|
Wire Gauge: AWG |
|
Flammability Rating: UL94V-0 |
