| Mating Cycle: 3,000 Cycles |
Voltage Rating: 300V AC (Power)
100V AC (Signal) |
Operating Temperature: -40°C to 105°C |
| Pullout Force:<120N | Current Rating: 80A+5A | IP Rating: IPX7(Mated) |
|
Wire Processing: Solder (Signal) / Plug Side
Crimp (Power) / Panel Side |
Withstand Voltage: 1,500V AC | Salt Spray: 5% NaCI, 48h |
|
Wire Gauge: Power 6AWG/Max Signal 22AWG/Max |
Insulation Resistance: 500MΩ at 500V DC | Flammability Rating: UL94V-0 |
