Rated Voltage: 48V AC / 60V DC
Rated Current: 15A+2A
Withstand Voltage: 500V AC
Insulation Resistance: 200MΩ Min at DC 500V
IP Rating: IP67 Mated
OperatingTemperature: -40°C to 85°C
Salt Spray: 5% Nacl, 48H
Mating Cycle: 1000 Cycles (Without load)
Wire Gauge: 16AWG/1.31mm²+ 24AWG/0.20mm²
Flammability Rating: UL94V-0
