| Mating Cycle: ≥3,000 Cycles |
Voltage Rating: 300V AC (Power)
100V AC (Signal) |
Operating Temperature: -40°C to 105°C |
| Pullout Force:<120N | Current Rating: 90A+5A | IP Rating: IP67(Mated), IP67 Panel Side |
|
Wire Processing: Solder (Signal) / Plug Side
Crimp (Power) / Panel Side |
Withstand Voltage: 2,000V AC (Power) 1,500V AC (Signal) |
Salt Spray: 5% NaCI, 48h |
|
Wire Gauge: Power 5AWG/Max Signal 20AWG/Max |
Insulation Resistance: 500MΩ at 500V DC | Flammability Rating: UL94V-0 (Plastic Material) |
