Mating Cycle：≥5,000 Cycles |
Voltage Rating：72V DC |
Operating Temperature：-40°C to 105°C |
|
Pullout Force：<100N |
Current Rating：40A + 5A |
IP Rating：IP67 Battery Side |
|
Wire Processing：Crimp |
Withstand Voltage：1,500V AC |
Salt Spray：5% Nacl, 48H |
|
Wire Gauge：Power 8AWG/ Max Signal 20AWG/ Max |
Insulation Resistance：>200MΩ at DC 500V |
Flammability Rating：UL94V-0 |
Products
FC09 3+10 Pin (40A+5A)
Applications: Charging & discharging application
Advantages
• 3 power + 10 signal pins layout
• 1mm self-floating
• 3.6mm Newsok power terminal - Chogori Patented technology
with high reliability, high current transmission capacity
• Bi-direction insertion
• RoHS and REACH compliant
