| Mating Cycle: 500 Cycles | Voltage Rating: 32V | Operating Temperature: -40°C to 105°C |
| Wire Processing: Solder | Current Rating: 5A | IP Rating: IP67(Mated) |
| Insulation Resistance: 100MΩ at 500V DC | Withstand Voltage: 1,500V AC | Salt Spray: 5% NaCI, 48h |
Wire Gauge: 24~22AWG | Flammability Rating: UL94V-0 |
Products
Large 24 Pin (5A) Push Lock
Applications: Signal Connector for Residential Energy Storage
Advantages
• Easy installation with push lock mechanism
• Reliable connection with IP67 protection
• Field installable available
• RoHS and REACH compliant
